Emerging as a beacon of hope in the quest for renewable energy, all-perovskite tandem solar cells are rapidly shaping the future of photovoltaic technology. These intricate devices leverage the unique optoelectronic properties of perovskite materials to transcend the inherent efficiency ceilings that limit traditional single-junction solar cells. By stacking two perovskite layers with complementary bandgaps in a tandem configuration, they can theoretically surpass the Shockley–Queisser limit, unlocking unprecedented power-conversion efficiencies while promising scalability and low manufacturing costs. Yet, bridging the gap between laboratory successes and commercial reality presents a formidable array of technical and engineering challenges that researchers are only beginning to unravel.
At its core, the allure of all-perovskite tandem photovoltaics lies in their potential to marry cost-effectiveness with exceptional efficiency gains. Perovskite materials, characterized by their ABX3 crystal structures, offer remarkable advantages, including tunable bandgaps through compositional adjustments and solution-processability. This tunability enables the design of tandem cells where a wide-bandgap top cell absorbs high-energy photons and a narrow-bandgap bottom cell captures lower-energy photons transmitted through the top layer. The synergy results in enhanced overall device efficiency that edges closer to the theoretical limits forecasted decades ago but impervious to conventional single-junction technologies.
Despite these compelling advantages, transferring breakthrough efficiencies achieved in small-area perovskite devices under controlled laboratory conditions to large-area, commercially viable modules remains a multifaceted challenge. The predominant fabrication method in the lab, spin coating, is ill-suited for scaling due to its material wastage, lack of uniformity over large substrates, and low throughput. Consequently, scalable deposition techniques such as blade coating, slot-die coating, and vapor-phase methods have gained traction. Each methodology carries trade-offs between film uniformity, crystallinity, and defect density, factors that critically influence device performance and reproducibility at scale.
